European standard channel steel is a hot-rolled U-shaped section steel manufactured according to European EN standards (e.g., EN 10279), featuring an inner flange slope of approximately 8%, with dimensional series and tolerances compatible with the British Standard (BS) system, and is widely used in load-bearing frames and mechanical supports in European and international engineering structures.

Email : iris@txdmetal.com
Phone/Whatsapp : +8615154137725
Addess : Huaiyin District,Jinan City,Shandong,China.

Description

Through channel steel is a structural steel with a "C"-shaped cross section. It is characterized by strong vertical bearing capacity, high structural strength, connection with other components by bolts or welding, and its lightweight design makes it lighter than "I"-shaped steel with diversified specifications.
Through channel steel can be divided into hot-rolled channel steel and cold-bent channel steel according to the production process, ordinary, light and heavy according to the cross-sectional shape, and carbon steel, stainless steel and weather-resistant materials according to the material.

Manufactured using precision rolling technology, our automated production line ensures consistent flange thickness (±0.5mm) and straightness tolerance (≤0.2% of length). Equipped with real-time monitoring systems, we achieve high dimensional accuracy and annual output of 300,000+ tons.

Commodity	Steel Channel
Standard	AISI, ASTM, DIN, GB, JIS, SUS
Certification	SGS, BV, etc
Thick	6#, 8#, 10#, 12#, 14#, 16#, 18#, 20#, 22#, 24# or as your requirements
Length	6 M or as customers' request
Surface	Bright, Polished, Turn smooth(Peeled),Brush, Mill, Pickled etc.
Delivery Time	7-15 days after confirming the order
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Trade Term	FOB, CIF, CFR
Payment Term	T/T or L/C
Advantage	Attracting Price; High surface quality,clean; Good appearance of whole coil; First-rate service.
MQQ	1 ton
Specifications	Type	Size	Size
	Stainless steel channel	6#, 8#, 10#, 12#, 14#, 16#, 18#, 20#, 22#, 24#	White acid & Hot rolled & Polished & Sandblas
	Stainless steel flat bar	193mm-20020mm	Black & Pickled & Bright
	Stainless steel square bar	Hot rolled: S10-S40mm Cold rolled: S5-S60mm	Hot rolled & Annealed & Pickled
	Stainless steel angle bar	25 * 25 * 2.5 mm - 150 * 150 * 12 mm	White acid & Hot rolled & Polished
	Stainless steel round bar	193mm-14012mm	Black & Pickled & Bright
	Stainless steel hexagon bar	Cold-rolled: S3.0mm-6.0mm Cold-drawn: S6.0mm-55mm Milling:S55mm-180mm	Cold-rolled, bright surface, some need to do heat treatment

PRODUCT DETAIL
U-bar
Dimensions and Sectional Properties
（1）EN10206-1:2000 EN10279:2000 EN10163-3:2004

Designation Designation Bezeichnung (imperial)	Unit Weight (kg/m)	Dimensions Abmessungen (mm)
Designation Designation Bezeichnung (imperial)	G	H	B	tw	t f	r
UPN 50*	5,59	50	38	5,0	7,0	7,0
UPN 65*	7,09	65	42	5,5	7,5	7,5
UPN 80*	8,64	80	45	6,0	8,0	8,0
UPN 100*	10,6	100	50	6,0	8,5	8,5
UPN 120	13,4	120	55	7,0	9,0	9,0
UPN 140	16,0	140	60	7,0	10,0	10,0
UPN 160	18,8	160	65	7,5	10,5	10,5
UPN 180	22,0	180	70	8,0	11,0	11,0
UPN 200	25,3	200	75	8,5	11,5	11,5
UPN 220	29,4	220	80	9,0	12,5	12,5
UPN 240	33,2	240	85	9,5	13,0	13,0
UPN 260	37,9	260	90	10,0	14,0	14,0
UPN 280	41,8	280	95	10,0	15,0	15,0
UPN 300	46,2	300	100	10,0	16,0	16,0
UPN 320*	59,5	320	100	14,0	17,5	17,5
UPN 350	60,6	350	100	14,0	16,0	16,0
UPN 380*	63,1	380	102	13,5	16,0	16,0
UPN 400*	71,8	400	110	14,0	18,0	18,0

UPE 80*	7,90	80	50	4,0	7,0	10
UPE 100*	9,82	100	55	4,5	7,5	10
UPE 120*	12,1	120	60	5,0	8,0	12
UPE 140*	14,5	140	65	5,0	9,0	12
UPE 160*	17,0	160	70	5,5	9,5	12
UPE 180*	19,7	180	75	5,5	10,5	12
UPE 200*	22,8	200	80	6,0	11,0	13
UPE 220*	26,6	220	85	6,5	12,0	13
UPE 240*	30,2	240	90	7,0	12,5	15
UPE 270*	35,2	270	95	7,5	13,5	15
UPE 300*	44,4	300	100	9,5	15,0	15
UPE 330*	53,2	330	105	11,0	16,0	18
UPE 360*	61,2	360	110	12,0	17,0	18
UPE 400*	72,2	400	115	13,5	18,0	18

Product Advantages

1.Channel steel has high strength and stiffness,can withstand large pressure and load, and is widely used in construction, manufacturing and transportation.
2.Channel steel is an economical construction steel with high cost performance and helps to reduce project costs.
3.The material of channel steel makes it have good plasticity and weldability, easy to process and install, and can meet the needs of different shapes and sizes.

Through channel steel has a wide range of applications and is used in construction and steel structure engineering, including building frames and supporting structures, roof and wall systems, temporary buildings and prefabricated structures; machinery manufacturing and equipment installation, reflected in machinery equipment bases and brackets, vehicles and transportation equipment, and agricultural and engineering machinery; bridges and transportation infrastructure, including bridge auxiliary structures, road facilities; cable trays and brackets and communication towers and signal bases in power and communication engineering; as well as furniture manufacturing and industrial style decoration, and other special applications such as shipbuilding and marine engineering and mining and energy equipment.

In order to ensure product quality, we will arrange professional personnel to check product quality, packaging, weight, hardness, etc., according to customer requirements of product specifications, looking for high-quality and cheap cooperative factories in China, to provide customers with one-stop procurement services and quality assurance.

Excellent packaging: Bundled with steel straps + waterproof wrapping，can effectively protect products from corrosion and various climate changes during transportation. Generally speaking, we ship from Shanghai, Tianjin, Qingdao and Ningbo ports. We have worked with many experienced shipping companies for a long time to find the most suitable mode of transportation for you.

OUR SERVICE:
1.Provide free sample.
2.We have full stock and can deliver within short time.
3.OEM and ODM order are accepted, Any kind of logo printing or design are available.
4.We offer you the different types of product.
5.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
6.All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
After you choose:
1. We will count cheapest shipping cost and send it to your email.
2. Start production immediately after receiving the advance payment.
3.About 10-15 working days to complete the production, and then the customer
FAQ
Q1: How many countries you already exported?

A1: Exported to more than 50 countries, mainly from Bangladesh, Indonesia,Philippines, Serbia, Brazil, Iraq, Israel, United Arab Emirates, etc.
Q2: How long will it take to execute my order?
A2: Delivery time of stock products: 3-7 days after payment. Custom product delivery time: 20-45 days after payment.
Q3：Can I have a sample for testing?
A3: The cost of the samples is according to the value. The cost of the freight is necessary.
Q4：Do you have inspection for the products before packing?
A4: All products have to go through three checks in the whole manufacturing process,it includes production and Random Testing in warehouse and Before Shipping.and accept the third party inspection .
Q5:Can I get your best price?
A5: Price is different based on steel grade, size and quantity.Our goal is to provide you the best price with great quality
assured in a long run.Please leave your contact information for the includes production.we will get back to you with the best solutions as soon as we can.Please give those info, for price checking.If the required is sheet metal fabrication, please send drawing.
Q6:How to order?
A6: Buyer sends the inquiry --> Buyer gets the quotation-->Order confirmation-->Buyer send the deposit-->Seller prepares
Q7：what kind of payment does your company support?
A7: T/T, L/C at sight, are all accepted.
