Chinese standard channel steel is a long strip of steel with a U-shaped cross-section, manufactured according to China's national standards (GB), and is widely used in building structures, machinery manufacturing, and engineering supports.
| Commodity | Steel Channel | ||
| Standard | AISI, ASTM, DIN, GB, JIS, SUS | ||
| Certification | SGS, BV, etc | ||
| Thick | 6#, 8#, 10#, 12#, 14#, 16#, 18#, 20#, 22#, 24# or as your requirements | ||
| Length | 6 M or as customers' request | ||
| Surface | Bright, Polished, Turn smooth(Peeled),Brush, Mill, Pickled etc. | ||
| Delivery Time | 7-15 days after confirming the order | ||
| Container Size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
||
| Trade Term | FOB, CIF, CFR | ||
| Payment Term | T/T or L/C | ||
| Advantage | Attracting Price; High surface quality,clean; Good appearance of whole coil; First-rate service. | ||
| MQQ | 1 ton | ||
Specifications |
Type | Size | Size |
| Stainless steel channel | 6#, 8#, 10#, 12#, 14#, 16#, 18#, 20#, 22#, 24# | White acid & Hot rolled & Polished & Sandblas | |
| Stainless steel flat bar | 19*3mm-200*20mm | Black & Pickled & Bright | |
| Stainless steel square bar | Hot rolled: S10-S40mm Cold rolled: S5-S60mm |
Hot rolled & Annealed & Pickled | |
| Stainless steel angle bar | 25 * 25 * 2.5 mm - 150 * 150 * 12 mm |
White acid & Hot rolled & Polished | |
| Stainless steel round bar | 19*3mm-140*12mm | Black & Pickled & Bright | |
| Stainless steel hexagon bar | Cold-rolled: S3.0mm-6.0mm Cold-drawn: S6.0mm-55mm Milling:S55mm-180mm |
Cold-rolled, bright surface, some need to do heat treatment | |
PRODUCT DETAIL
U-bar
Dimensions and Sectional Properties
（1）GB/T706-2016
|
Specifications |
Designation |
Unit Weight (kg/m) |
Specifications |
Designation |
Unit Weight (kg/m) |
|
KG |
KG |
||||
|
5# |
50*37*4.5 |
5.44 |
25#A |
250*78*7 |
27.4 |
|
6.3# |
63*40*4.8 |
6.63 |
25#B |
250*80*9 |
31.3 |
|
8# |
80*43*5.0 |
8.04 |
25#C |
250*82*11 |
35.3 |
|
10# |
100*48*5.3 |
10 |
28#A |
280*82*7.5 |
31.4 |
|
12# |
120*53*5.5 |
12.1 |
28#B |
280*84*9.5 |
35.8 |
|
12.6# |
126*53*5.5 |
12.3 |
28#C |
280*86*11.5 |
40.2 |
|
14#A |
140*58*6 |
14.5 |
30#A |
300*85*7.5 |
34.5 |
|
14#B |
140*60*8 |
16.7 |
30#B |
300*87*9.5 |
39.2 |
|
16#A |
160*63*6.5 |
17.2 |
30#C |
300*89*11.5 |
43.9 |
|
16#B |
160*65*8.5 |
19.8 |
32#A |
320*88*8 |
38.1 |
|
18#A |
180*68*7 |
20.2 |
32#B |
320*90*10 |
43.1 |
|
18#B |
180*70*9 |
23 |
32#C |
320*92*12 |
48.1 |
|
20#A |
200*73*7 |
22.6 |
36#A |
360*96*9 |
47.8 |
|
20#B |
200*75*9 |
25.8 |
36#B |
360*98*11 |
53.5 |
|
22#A |
220*77*7 |
25 |
36#C |
360*100*13 |
59.1 |
|
22#B |
220*79*9 |
28.5 |
40#A |
400*100*10.5 |
58.9 |
|
24#A |
240*78*7 |
26.9 |
40#B |
400*102*12.5 |
65.2 |
|
24#B |
240*80*9 |
30.6 |
40#C |
400*104*14.5 |
71.5 |
|
24#C |
240*82*11 |
34.4 |
|||
1.Channel steel has high strength and stiffness,can withstand large pressure and load, and is widely used in construction, manufacturing and transportation.
2.Channel steel is an economical construction steel with high cost performance and helps to reduce project costs.
3.The material of channel steel makes it have good plasticity and weldability, easy to process and install, and can meet the needs of different shapes and sizes.
Excellent packaging: Bundled with steel straps + waterproof wrapping，can effectively protect products from corrosion and various climate changes during transportation. Generally speaking, we ship from Shanghai, Tianjin, Qingdao and Ningbo ports. We have worked with many experienced shipping companies for a long time to find the most suitable mode of transportation for you.
